After the adjustment the securing
screw (SC) must be tightened ca-
refully, to avoid an unintentional
adjusting of the stop eccenter.
During work the spring loaded pin
(51) must be unlocked. Then the
handle (77) of the pin points to the
drive wheel.
For transport the drive wheel must be swung upwards and locked in this po-
sition by means of the pin. Then the grip of the pin points to the pivot axle (79).
See section „Wheel pressure increasing device"!
45
