22 MAINTENANCE

IMPORTANT: Do not clean this implement with a Pressure Washer during
the first 6 weeks. After this time a minimum nozzle distance of
60 cm must be observed with a maximum 100 bar and 50 ° C
temperature!
The life time of the seed drill depends on good maintenance. Therefore pay
attention to the following points.

22.1 Gear box

The stepless gear box (20) and
angle gear box (76) are filled with
hydraulic oil when delivered. The
oil level in the gear boxes must be
checked regularly.
The oil must stand until the control
screew (92).
With the angle gear box the oil le-
vel may only be checked with ho-
rizontal position of the of the drive wheel (58).
Oil table for gear box (20) and switch gear box (76):
ARAL
BP
CHEVRON
ESSO
MOBIL
SHELL
TEXACO
70
ARAL OEIL DEGOL BG 46
BP Energol GR-XP 46
CHEVRON ATF
CHEVRON EP industrial 46
NUTO H 46
MOBIL DTE 25
DONAX TM
RANDO OIL DK B 46
