ROLLERS OF THE POWER HARROWS ZIRKON

In order to prevent that the coulters do not touch the roller during lifting pro-
cedure and to ensure that the hopper can be swung safely, with reference to
the rollers the following items must be adhered to:
1. The tube bar roller RSW 540 must be connected to the carrier of the roller
in position B.
2. All Ø 500 mm rollers of the Zirkon power harrows must be connected to
the carrier of the roller in position B, when the tines are worn more than
50 %.
position A position B
