Tramline Rhythm - LEMKEN Saphir 8 AutoLoad Operating Instructions Manual

Operation

9.2.2 Tramline rhythm

There is a choice of two different tramline rhythms:
Odd rhythm
With an odd tramline rhythm, the working width of the field sprayers or fertiliser
spreaders can be larger than that of the seed drill by an odd integer factor.
Example:
Sprayer
12 metres
The tramline rhythm in this example is 3. Tramlines are created if the current track
is the same as the entered tramline rhythm. The number of tracks is incremented
each time the seed drill is raised. Thus, tramlines are created every third seed drill
lift.
For more information, see the operating instructions of the electronic seed drill
control system.
Seed drill
4 metres
Tramline rhythm
3
57
