5.4.4 Seed wheels

a) Seed wheel Conti-Plus
The two-parts Seed Wheel CONTI-PLUS can be adjusted in two different ad-
justment positions.
Normal seed wheel (N):
This adjustment, where the normal seed wheel (N) is switched on,
will be chosen for all all sorts of crops and big-grained seed.
Fine seed wheel (F):
This adjustment, where the fine seed wheel is switched on, will be
used for fine seed.
Switching on and off the fine- and normal seed wheel (seed wheel hal-
ves)
By means of moving the red cam
slide (55) to the inside, each seed
wheel will be switched on. At the
same time the cam slide of the
other seed wheel will be moved to
the outside and so the seed wheel
switched off. The cam slided moved
outside supports at the seed wheel
housing and prevents a turning of
the switched off seed wheel.
The operation of the cam slide can
be done manual or by a small screw
driver.
