4.2 Attaching the seed drill

After the hydraulic three-point lin-
kage (HA) of the LEMKEN soil cul-
tivation implement has been
equipped with attaching parts (1)
respectively the coupling parts are
fitted, the machine parked on its
stands (A2) can be attached.
With the version with coupling
parts for LEMKEN-soill cultivation
implements it must be ensured
that the top link of the three point linkage is dismounted and the catching hook
(FH) is fitted and secured.
When attaching to a foreign model or a tractor, the instructions of the corres-
ponding operating manual (foreign model or tractor) must be adhered to.
After attachment the drawbar (90) must be secured by means of the securing
lash (72) and the securing pin (73).
Connect electric cables and hydraulic hoses.
Finally the Saphir 7 must be lifted
until the stands (2) are unloaded
so that they can be removed out of
the frame tube (53).
