5.5 Calibration test

For checking the adjusted seed
rate a calibration test must be car-
ried out.
The operation terminal will be put
into the holer (1) during calibration
test so that it can be seen by the
operator at any time.
a) Adjust soil flaps, slides and
seed wheels according to the
seeding table.
b) Fill the hopper.
c) Move out laterally both calibra-
tion trays (6) and move them in
again with the opening to the
top. Before the calibration test,
clean the trays when they are
dirty.
d) Set emptying flaps to the cali-
bration position by means of
pressing down the emptying le-
ver (13) so that the hexagon
shaft (57) turns.
e) Adjust gear box to maximum po-
sition = 150, with peas and
beans to 80.
f) Set drive wheel (66) to middle
position and put calibration lever
(86) upon the shaft of the gear box (76).
35
