5.2.2 Saphir 7 with seed wheels Mega Plus

Seed
Big peas and
beans
* Gear box adjustment for the first calibration test
a) Switch off agitator shaft
b) Fit grass seed agitator device
The adjustment information for the setting of the seed drill and the adjustment
of the first calibration test can be taken from the seeding table.
After the 1st calibration test and for each following calibration test the opti-
mum gear box adjustment will be indicated on the display of the operation ter-
minal. See operating instructions for the electronic seed drill control
Easytronic.
ATTENTION! Do not put parts into the hopper, as the agitator shaft turns
when moving the implement and damages can occur.
a b
Soil flap
5
Adjustments
Seed wheel Slide Gear box
1 - 2 45
27
