1.8
Connectors
Connectors connect the board with other parts of the system. Loose or improper connection might cause
problems. Make sure all connectors are properly and firmly connected.
Here is a table summarizing all connectors on the board.
Connector
MINI Card slot
LAN1+USB3.0
LAN2+USB3.0
DVI-D connector
DP++ connector
USB 3.2 connector (H610E Only support USB2.0)
Audio connector
DC-in Phoenix power connector
HDMI connector
M.2 2280 Key M NVMe SSD
COM port connector
SATA Power connector (+5V Only)
SATA III connector
DDR5 SO-DIMM (262 Pin)
Power button
Remote SW/LED ; IGN control
MIO530 Module Kit,M2 Key B,M2 Key E (IPC964A Only)
Flexible IO-AX93511 COM x4 (RS232/422/485)
Flexible IO-AX93516 isolated COM x4 (RS232/422/485)
Flexible IO-AX93512 isolated COM x2 (RS232/422/485) & 8in/8out DIO
Flexible IO-AX93519 COM x2 (RS232/422/485), USB x2 & LAN1
Flexible IO-MIO160 6 x Serial port (4-wire RS232:
TXD/RXD/RTS/CTS)/422/485 isolated 1.5kVDC & 2 CAN bus with isolated
1.5kVDC module(supports the CAN 2.0A and CAN2.0B protocol
specification)
Riser card card Card - EIO141 1 PCIe x 16 Gen4 + I PCIe x8 Gen3(x4
Introduction
IPC960A/IPC962A/IPC964A Series User's Manual
Label
CN7
CN8
CN9
DVI1
CN2
CN6
CN4
CN13
CN1
CN5
COM1
SATAPWR1~2
SATA1~2
SODIMM1~2
SW1
CN12
CN3
SCN1
SHB1+SHB2
15
