1.2.3 Specification

System chipset
BIOS
System memory
Ethernet
Serial
USB
Display
Audio
TPM
Extension system I/O
module (optional)
Riser card
Expansions
Storage
System indicator
Power input
Inrush current
Power rating
Storage temperature
Humidity
Introduction
IPC960A/IPC962A/IPC964A Series User's Manual
IPC960A IPC962A
H610E H610E
AMI BIOS with Smart View and Customer CMOS Backup
2x DDR5 4800/4000 un-buffered SO-DIMM, max up to 64GB
1 x 1GbE Intel i219LM (w/ Intel AMT)
1 x RS232/422/485 (default RS232) COM1
2 x USB3.2 Gen2x1(10G)
2 x USB3.2 Gen1x1(5G)
2 x USB2.0
1 x DVI-D with 1920 x 1200 resolution supported
1 x HDMI with 4096 x 2304 resolution supported
1 x DP++ with 4096 x 2304 resolution supported
1 x 3.5mm jack for Line out and Mic-in
AX93511, AX93512, AX93516, AX93519, MIO160
EIO121
N/A
EIO122
1 x mPCIe socket w/ SIM
slot
1 x 2.5" HDD/SSD tray w/ Inte VMD supported (7/9.5/15mm height)
1 x M.2 key M 2280 socket (PCIe x4 Gen4)
1 x HDD/SSD access LED
Power input 18 to 36 VDC
1 x switch for ower on/off with LED (default ATX)
1 x 4-pin Terminal Block for DC input
1 x 4-pin Terminal Block for ignition control, remote power and remote
24Vdc, 6A 24Vdc, 11A
10%-90% (non-condensing)
IPC960A IPC962A
Q670E Q670E
1 x 2.5GbE Intel i226V
6 x USB3.2 Gen2x1 (10G)
1 x USB2.0 (internal, type A, up to 30mm)
1 x TPM 2.0 on board
EIO121
N/A
EIO122
1 x mPCIe socket w/ SIM slot
1 x M.2 key E 2230 + 1 x M.2 key B 3052 w/
SIM slot (optional)
3 x user's LED
LED
+24V/10.8A
24Vdc, 6A 24Vdc, 11A
-20℃-80℃
IPC964A
Q670E
EIO141
EIO142
24Vdc,
13.5A
