EIO141: 1 PCIe x 16 Gen4 + I PCIe x8 Gen3(x4 signal) + 2 PCIe x4 Gen4 (open ended
➢
connector)
1 USB2.0 type A 180D
1 Fan connector
2 8-pin power connector
1 4-pin power connector
EIO142: 1 PCIe x 16 Gen4 + I PCIe x4 Gen4 (open ended connector) + 2 PCI
➢
1 USB2.0 type A 180D
1 Fan connector
2 8-pin power connector
1 4-pin power connector
Note: The maximum power rating for expansion slots at 70℃ cannot exceed the following
value:
The maximum loading of +3.3V+5V+12V+24V<350W
Note: 12V maximum loading for 2 x 8-pin connectors (ATX2-3) are 8.33A(200W).
Note: 24V maximum loading for 1 x 4-pin connector (ATX1) is 5A(120W).
Note: The system power rating may thus be changed base on differing combinations of
attached devices.
