1.8

Connectors

Connectors connect the board with other parts of the system. Loose or improper connection
might cause problems. Make sure all connectors are properly and firmly connected.
Here is a table summarizing all connectors on the board.
Connector
MINI Card slot
LAN1+USB3.0
LAN2+USB3.0
VGA connector
USB 2.0 connector
Audio connector
DC-in Phoenix power connector
HDMI connector
M.2 2280 Key M NVMe SSD
M.2 3050 Key B
COM port connector
SATA Power connector
SATA III connector
DDR4 SO-DIMM (260 Pin)
Power button
AT/ATX Power select
Remote SW
Flexible IO-AX93511 COM x4 (RS232/422/485)
Flexible IO-AX93516 isolated COM x4 (RS232/422/485)
Flexible IO-AX93512 isolated COM x2 (RS232/422/485) & 8in/8out DIO
Flexible IO-AX93519 COM x2 (RS232/422/485), USB3.0 x2 & LAN1
Riser Card-AX96205 PCIe x16 Gen3 & 1 PCIe x4 Gen 3
Riser Card-AX96206 PCIe x16 Gen3 & 1 PCI
Riser Card-AX96207 2 PCI
Riser Card –AX96410 PCIe x16 Gen3 & 3 PCIe x4 Gen 3
Riser Card –AX96411 PCIe x16 Gen3 & 1 PCIe x4 Gen 3 & 2 PCI
Introduction
IPC960/IPC962/IPC964-525 Series User's Manual
Label
CN4
CN9
CN10
CN3
CN13
CN1
CN12
CN2
CN8
CN5
COM1
SCN2
SATA1~2
、
SDIMM1
SDIMM2
SW2
SW3
PWRBT1
SCN1
SHB1+SHB2
