Step 6
Plug fan module cable(s) to connector(s).
IPC962A
Step 7
After installing the fan module, close the system cover back to the chassis and fasten the screw.
Installation is complete.
Note: Reserve at least 25mm space from the rear side for optimal fan air flow.
2.7
Installing PCI or PCIe Card
The IPC962A/IPC964A provides two/four PCI or PCIe slots for expansion. The procedure of installing PCI
/ PCIe expansion cards into system is instructed below.
2.7.1 Installing PCI or PCIe card
Step 1
Turn off the system.
Step 2
Disconnect the power connector.
Step 3
Loosen the system cover screw and remove the cover from the expansion box.
Hardware Installation
IPC960A/IPC962A/IPC964A Series User's Manual
IPC964A
51
