Connectors

1.2.25
Signals go to other parts of the system through connectors. Loose or improper
connection might cause problems, please make sure all connectors are properly and
firmly connected. Here is a summary table which shows all connectors on the hardware.
PSB519
3 pin terminal block for Power Input
Battery Connector
DDR4 SODIMM Socket
HDMI output Connector
USB3.1 *2 Connector
LAN connector
M.2 B-key 3052/3042 (USB3.1 / PCIe interface)
Nano SIM card slot
Mini Card Solt1(USB2.0 / PCIe interface)
Mini Card Solt2(USB2.0 / mSATA interface)
Board-to-Board Connector
SATA+Power
Tact switch for clear CMOS
Tact switch for Reset
MIO105(Full Type)
Board-to-Board Connector
COM Port with RS232 / RS422 /RS485
Digital I Connector
Digital O Connector
NVMe M.2 2240/2280 PCIe Gen2x4
16
Connectors
Connectors
Label
CN3
BAT1
DIMM1
CN12/CN15
CN8/CN14
LAN1/LAN2/LAN3/LAN4
CN1
CN4/CN9/CN13
CN10
CN11
PCIE1
CN5/CN6
SW1
CN7
Label
PCIe1
CN1/CN2
CN3
CN4
SCN1
