Note: The followings show each slot's max. dimensions for add-in card in the system , it doesn't
include power cable routing length required for add-in card.
Fan-less or external fan module is installed
height
width
The following shows each slot's max. length for add-in card in the system with different
configurations.
4-pin ATX power
cable is un-
installed.
4-pin ATX power
Hardware Installation
IPC960A/IPC962A/IPC964A Series User's Manual
Slot 1
(PCIe x16)
46.08-116.38 (mm)
1-slot
264.27 (mm)
Slot 2
(PCIe x4 or PCI)
2-slot
229.98-264.27 (mm)
55
