IPC960A/IPC962A/IPC964A Series User's Manual
1.8.2 LAN+USB3.2 (CN8, CN9)
The system has two RJ-45 connectors: LAN1 and LAN2. Ethernet connection can be established by
plugging one end of the Ethernet cable into this RJ-45 connector and the other end (phone jack) to a
2500/1000/100/10-Base-T hub.
Port
LAN LED
A
CN8
B
A
CN9
B
18
Descriptions
Speed LED:
Link 10
off
Link 100
Green
Link 1000
Orange
Active Link LED:
Active
Yellow Blinking
Speed LED:
Link 10
off
Link 100
off
Link 1000
Orange
Link 2500
Green
Active Link LED:
Active
Yellow Blinking
