Mark Description
1 DVI-D with 1920 x 1200 resolution
2 RS232/422/485 (default RS232) COM1
3 1GbE Intel i219LM (w/ Intel AMT
4 2.5GbE Intel i226V
5 4-pin Terminal Block for ignition control, remote power and remote LED
6 2 x 2.5" HDD/SSD tray
1 x HDD/SSD access LED
7
3 x user's LED
8 Switch for ower on/off with LED (default ATX)
9 HDMI with 4096 x 2304 resolution
10 DP++ with 4096 x 2304 resolution
11 3.5mm jack for Mic-in and Line-out
12 2 x USB2.0(H610E) or 2 x USB3.2 Gen2x1 10G (Q670E)
13 2 x USB3.2 Gen2x1 10G
Extension system IO window for AX93511, AX93512, AX93516, AX93519 and
14
MIO160
15 4-pin Terminal Block for DC input
16 Expansion slots for EIO121 or EIO122 (riser card)
17 Expansion slots for EIO141 or EIO142 (riser card)
