IPC960A/IPC962A/IPC964A Series User's Manual
Step 6
Paste the other thermal pad on the module and then remove the protective film.
Step 7
Close the heatsink cover back to the chassis and fasten all screws. The installation is complete.
2.4
Installing the Hard Disk Drive
The IPC960A/IPC962A/IPC964A offers two convenient drive bay modules for users to install HDD/SSD.
The system offers users two 2.5" Hard Disk Drives for installation. Please follow the steps to install:
Step 1
Turn off the system.
Step 2
Disconnect the power connector.
Step 3
Unscrew 2 screws for each HDD tray and separating the HDD tray from the chassis.
Step 4
Fix HDD/SSD to the HDD tray with four screws
Step 5
Insert HDD tray to main box, then screw 2 screws for each HDD tray. Installation is complete.
46
→
Hardware Installation
