IPC960A/IPC962A/IPC964A Series User's Manual
2.6
Installing the Fan Module
The IPC962A/IPC964A provides either an internal fan module or an external fan module for optional
selection. The procedure of installing the fan module into system is instructed below.
Step 1
Turn off the system.
Step 2
Disconnect the power connector.
Step 3
Loosen the system cover screw and remove the cover from the expansion box.
Step 4
Loosen the screw to remove the bracket.
Step 5
Fasten the fan module into the expansion box.
Tighten a screw to fix the fan
module into chassis.
50
IPC962A
IPC964A
Tighten a screw to fix the fan module
into chassis.
Hardware Installation
