Summary of Contents for AXIOMTEK IPC960-525 Series

  • Page 1 IPC960-525 series IPC962-525 series IPC964-525 series Industrial Computers User’s Manual...
  • Page 2 Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice.

  • Page 3: Safety Precautions

    Safety Precautions Before getting started, please read the following important safety precautions. The IPC960-525/IPC962-525/IPC964-525 Series does not come equipped with an operating system. An operating system must be loaded first before installing any software into the computer. Be sure to ground yourself to prevent static charge when installing the internal components.

  • Page 4: Classification

    Classification 1. Degree of production against electric shock: not classified 2. Degree of protection against the ingress of water: none Equipment not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide. 4.
  • Page 5 Cleaning Tools: Although many companies have created products to help improve the process of cleaning your computer and peripherals users can also use household items to clean their computers and peripherals. Below is a listing of items you may need or want to use while cleaning your c omputer or computer peripherals.

  • Page 6: Scrap Computer Recycling

    Scrap Computer Recycling Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in case computers require maintenance or repair; or for recycling in case computers are out of order or no longer in use. Trademark Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd.

  • Page 7: Table Of Contents

    Table of Contents Safety Precautions ....................iii Classification ......................iv General Cleaning Tips ..................iv Scrap Computer Recycling .................. vi SECTION 1 INTRODUCTION................. 1 General Description ................1 System Specifications ............... 2 1.2.1 Main CPU Board ....................2 1.2.2 I/O System ......................3 Dimensions ..................
  • Page 8 Installing the Fan Module ..............53 2.6.1 Installing Internal Fan Module ..............53 2.6.2 Installing external Fan Module ..............55 Installing PCI or PCIe Card .............. 56 2.7.1 Installing PCI or PCIe card ................56 2.7.2 The height limitation of an add-on card ............59 2.7.3 The length limitation of an add-on card ............

  • Page 9: Section 1 Introduction

    IPC960/IPC962/IPC964-525 Series User’s Manual SECTION 1 INTRODUCTION This chapter contains general information and detailed specifications of the IPC960- 525/IPC962-525/IPC964-525 Series. Chapter 1 includes the following sections:  General Description  System Specifications  Dimensions  I/O Outlets  Jumper Settings ...

  • Page 10: System Specifications

    IPC960/IPC962/IPC964-525 Series User’s Manual System Specifications 1.2.1 Main CPU Board  ®  Socket LGA1151 for 9 Generation Intel Core i7/i5/i3 processors, up to  Below is a list of supported CPUs. Proc No WATT Core Thread Base frequency Generation Coffee Lake-S refresh i9-9900 3.1 GHz...

  • Page 11: 1.2.2 I/O System

    IPC960/IPC962/IPC964-525 Series User’s Manual Coffee Lake-S G4920 3.2 GHz Coffee Lake-S i7-8700T 2.4 GHz Coffee Lake-S i5-8600T 2.3 GHz Coffee Lake-S i5-8500T 2.1 GHz Coffee Lake-S i5-8400T 1.7 GHz Coffee Lake-S i3-8100T 3.1 GHz Coffee Lake-S i3-8300T 3.2 GHz Coffee Lake-S G5400T 3.1 GHz Coffee Lake-S...
  • Page 12 IPC960/IPC962/IPC964-525 Series User’s Manual  Two USB 2.0 ports Note: IPC960-525 series support a internal USB2.0 with 180D type A connector for license key, up to 30mm)  One HDD/SSD access LED  Three user’s LEDs  Two G.E. LAN ports (i211AT & I219LM) ...
  • Page 13 IPC960/IPC962/IPC964-525 Series User’s Manual 1 x AX96410: 1 PCIex16 + 3 PCIex4 or 1 x AX96411: 1 PCIex16 + 1 PCIex4 + 2PCI ℃ Note: The maximum power rating for expansion slots at 60 cannot exceed the following value: The maximum loading of +3.3V+5V+12V<150W Note: 12V maximum loading is 12A(144W).
  • Page 14 IPC960/IPC962/IPC964-525 Series User’s Manual Coffee Lake-S i3-9300 -10℃-50℃ 3.7 GHz refresh Coffee Lake-S G4950 -10℃-50℃ 3.3 GHz refresh Coffee Lake-S G4930 -10℃-50℃ 3.2 GHz refresh Coffee Lake-S i7-9700TE -10℃-60℃ 1.8 GHz refresh Coffee Lake-S i7-9700T -10℃-60℃ 2.0 GHz refresh Coffee Lake-S i5-9600T -10℃-60℃...
  • Page 15 IPC960/IPC962/IPC964-525 Series User’s Manual Coffee Lake-S G5400T -10℃-60℃ 3.1 GHz Coffee Lake-S G4900T -10℃-60℃ 2.9 GHz * The IPC system may cause CPU frequency hopping when operating in an extremely high temperature environment, and thermal throttling may occur when the system remains in full loading conditions.

  • Page 16: Dimensions

    IPC960/IPC962/IPC964-525 Series User’s Manual Dimensions The following diagrams show you dimensions and outlines of the IPC960-525/IPC962- 525/IPC964-525 Series. IPC960-525 IPC962-525 Introduction...
  • Page 17 IPC960/IPC962/IPC964-525 Series User’s Manual IPC964-525 Introduction...

  • Page 18: I/O Outlets

    IPC960/IPC962/IPC964-525 Series User’s Manual I/O Outlets The following figures show locations of the IPC900 series I/O outlets IPC960-525 Front Panel Mark Description 1 x HDD/SSD access LED 3 x User's LED 1 x 4-pin terminal block 1 x RS-232/422/485 (default RS-232) 2 x LAN Introduction...
  • Page 19 IPC960/IPC962/IPC964-525 Series User’s Manual 1 x VGA 1 x HDMI 1 x Switch for power on/off w/LED Extension system I/O module 1 x Line out 1 x Remote switch 2 x USB2.0 4 x USB 3.1 1 x AT/ATX switch (default ATX) 1 x Terminal ground Introduction...
  • Page 20 IPC960/IPC962/IPC964-525 Series User’s Manual IPC962-525 Front Panel Mark Description 1 x HDD/SSD access LED 3 x User's LED 1 x 4-pin terminal block 1 x RS-232/422/485 (default RS-232) 2 x LAN 1 x VGA 1 x HDMI Introduction...
  • Page 21 IPC960/IPC962/IPC964-525 Series User’s Manual Riser (PCIe/PCI slots expansion) 1 x Switch for power on/off w/LED Extension system I/O module 1 x Line out 1 x Remote switch 2 x USB2.0 4 x USB 3.1 1 x AT/ATX switch (default ATX) 1 x Terminal ground Introduction...
  • Page 22 IPC960/IPC962/IPC964-525 Series User’s Manual IPC964-525 Front Panel Mark Description 1 x HDD/SSD access LED 3 x User's LED 1 x 4-pin terminal block 1 x RS-232/422/485 (default RS-232) 2 x LAN 1 x VGA Introduction...
  • Page 23 IPC960/IPC962/IPC964-525 Series User’s Manual 1 x HDMI Riser (PCIe/PCI slots expansion) 1 x Switch for power on/off w/LED Extension system I/O module 1 x Line out 1 x Remote switch 2 x USB2.0 4 x USB 3.1 1 x AT/ATX switch (default ATX) 1 x Terminal ground Introduction...

  • Page 24: Packing List

    Terminal block x 1  Remote switch cable x 1  Holder bracket kit x1 (for IPC962/IPC964)  HDD spacer x1 (for 7mm height SSD/HDD) If you cannot find this package or any items are missing, please contact Axiomtek distributors immediately. Introduction...

  • Page 25: M/B Block Diagram

    IPC960/IPC962/IPC964-525 Series User’s Manual M/B Block Diagram The following diagram shows you the M/B block diagram of SBC87525. Introduction...

  • Page 26: Jumper Settings

    IPC960/IPC962/IPC964-525 Series User’s Manual Jumper Settings Properly configure jumper settings on the SBC87525 to meet your application purpose. Below you can find a summary table of all jumpers and onboard default settings. Note: How to setup Jumpers Illustrations below show that a cap on a jumper is to “close” the jumper, whereas that off a jumper is to “open”...

  • Page 27: Connectors

    IPC960/IPC962/IPC964-525 Series User’s Manual Connectors Connectors connect the board with other parts of the system. Loose or improper connection might cause problems. Make sure all connectors are properly and firmly connected. Here is a table summarizing all connectors on the board. Connector Label MINI Card slot...

  • Page 28: Mini Card Slot (Cn4)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.1 MINI Card Slot (CN4) A PCI-Express Mini Card connector is located on the top side . It follows mini PCIe 1.2 standard. Pins Signals Pins Signals WAKE# +3.3VSB No use No use +1.5V CLKREQ# No use No use REFCLK- No use...

  • Page 29: Lan+Usb3.0 (Cn9, Cn10)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.2 LAN+USB3.0 (CN9, CN10) The system has two RJ-45 connectors: LAN1 and LAN2. Ethernet connection can be established by plugging one end of the Ethernet cable into this RJ-45 connector and the other end (phone jack) to a 1000/100/10-Base-T hub. 1000 100/10 Pins...

  • Page 30: Vga Connector (Cn3)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.3 VGA Connector (CN3) The CN9 is a 15-pin D-Sub connector which is commonly used for connecting a CRT monitor. Pins Signals Pins Signals Green Blue N.C. DETECT N.C. DDC DATA Horizontal Vertical Sync Sync DDC CLK Introduction...

  • Page 31: Usb 2.0 Connector (Cn13)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.4 USB 2.0 Connector (CN13) The Universal Serial Bus connectors are compliant with USB 2.0 (480Mbps), providing ideal interfaces ideal for installing USB peripherals such as a keyboard, mouse, scanner, etc. Pin Signal USB Port 0 Signal USB Port 1 USB VCC USB VCC...

  • Page 32: Hdmi Connector (Cn2)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.7 HDMI Connector (CN2) The HDMI (High-Definition Multimedia Interface) is a compact digital interface which is capable of transmitting high-definition video and high-resolution audio over a single cable. Pins Signals Pins Signals HDMI OUT_DATA2+ HDMI OUT Clock- HDMI OUT_DATA2- N.C.

  • Page 33: 2280 Key M Nvme Ssd (Cn8)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.9 M.2 2280 Key M NVMe SSD (CN8) The M.2 2280 Key M NVM Express SSD for storage. Signal Signal Signal Signal +3.3V +3.3V PERn3 PERp3 LED_1# PETn3 +3.3V PETp3 +3.3V +3.3V PERn2 +3.3V PERp2 PETn2 PETp2 PERn1 PERp1...

  • Page 34: 3050 Key B (Cn5)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.10 M.2 3050 Key B (CN5) Signal Signal Signal Signal CONFIG_3 +3.3V +3.3V Full Card PWR USB_D+ W_DISABLE1# USB_D- GPIO_9 Key B Key B Key B Key B Key B Key B Key B Key B GPIO_5 CONFIG_0 GPIO_6...

  • Page 35: Sata Power Connector (Scn2)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.11 SATA Power Connector (SCN2) The SATA power connector is used for interfacing SATA 2.5" HDD/SSD power supply. Pins Signals +12V level +5V level 1.8.12 SATA Connector (SATA1~SATA2) These Serial Advanced Technology Attachment (Serial ATA or SATA) connectors are used as high-speed SATA interfaces.

  • Page 36: At/Atx Switch (Ssw1)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.14 AT/ATX Switch (SSW1) If you set AT/ATX switch to AT mode, the system will be automatically powered on without pressing the soft power button during power input; we can use this switch to achieve auto power on demand.

  • Page 37: Flexible Io - Isolated Com X4 I/O Card (Ax93516)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.17 Flexible IO – Isolated COM x4 I/O Card (AX93516) The system has an optional four serial ports module. COM2~COM5 are RS-232/422/485 w/isolated 2KV ports. Please refer to Chapter 4 for the details of BIOS setting. ※COM2,COM3,COM4,COM5 Pins RS-232...

  • Page 38: Flexible Io - Isolated Com & Dio I/O Card (Ax93512)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.18 Flexible IO – Isolated COM & DIO I/O Card (AX93512) The system has an optional module to support COM2~COM3, which are RS- 232/422/485 with isolated 1.5KVDC protection and DIO1~DIO2 8 -in/8-out isolated 1.5KVDC DIO ports. Please refer to Chapter 4 for the detail s of BIOS setting. ※COM2,COM3,DIO1,DIO2 CN1 (COM2)&...
  • Page 39 IPC960/IPC962/IPC964-525 Series User’s Manual Digital I/O Specification (per port)  Isolated Digital Input The figure shows how to connect between external input source and the system. Each of the isolated digital input channels accepts 0~30 VDC with sink type and source type. ...

  • Page 40: Flexible Io- Usb3.0X2 & Comx2(Rs232/422/485) & Lan(Ax93519)

    IPC960/IPC962/IPC964-525 Series User’s Manual 1.8.19 Flexible IO- USB3.0x2 & COMx2(RS232/422/485) & LAN(AX93519) The system has an optional module to support two USB, two RS232/422/485 & one LAN. Please refer to Chapter 4 for the details of BIOS setting.  AX93519 2 x RS232/422/485 + 1 G.E. LAN(i211AT) + 2 USB.3.1(1 USB3.1 Gen.2 signal &...
  • Page 41 IPC960/IPC962/IPC964-525 Series User’s Manual The system has two serial ports. COM2~COM3 are RS-232/422/485 ports. Please refer to Chapter 3 for the detail of BIOS setting. ※COM2,COM3 Pins RS-232 RS-422 RS-485 DCD, Data Carrier Detect Data- Data+ RXD, Receive Data No use TXD, Transmit Data No use DTR, Data Terminal Ready...

  • Page 42: Riser Card- Pcie X16 Gen3 & 1 Pcie X4 Gen 3(Ax96205)

     1 x system fan connectors  1 x 24V power connector (black, ATX1, for Axiomtek’s device only)  1 x 12V power connector (white, ATX2, for Axiomtek’s device only) Note: Please refer to chapter 1.2.2 for the maximum power rating limitation of expansion slots.
  • Page 43 Temperature Sensor Source Select (JP1) Use these jumpers (3x1-Pin P=2.54mm) to set temperature sensor source to operate from external or onboard mode. Onboard Sensor (Default) 1-2 close Function Setting On Board Thermistor Reserved Pin 3 is reserved for Axiomtek’s device use only. ※ Introduction...

  • Page 44: Riser Card- Pcie X16 Gen3 & 1 Pci(Ax96206)

     1 x system fan connectors  1 x 24V power connector (black, ATX1, for Axiomtek’s device only)  1 x 12V power connector (white, ATX2, for Axiomtek’s device only) Note: Please refer to chapter 1.2.2 for the maximum power rating limitation of expansion slots.
  • Page 45 Temperature Sensor Source Select (JP1) Use these jumpers (3x1-Pin P=2.54mm) to set temperature sensor source to operate from external or onboard mode. Onboard Sensor (Default) 1-2 close Function Setting On Board Thermistor Reserved Pin 3 is reserved for Axiomtek’s device use only. ※ Introduction...

  • Page 46: Riser Card- 2 Pci (Ax96207)

     1 x system fan connectors  1 x 24V power connector (black, ATX1, for Axiomtek’s device only)  1 x 12V power connector (white, ATX2, for Axiomtek’s device only) Note: Please refer to chapter 1.2.2 for the maximum power rating limitation of expansion slots.
  • Page 47 Temperature Sensor Source Select (JP1) Use these jumpers (3x1-Pin P=2.54mm) to set temperature sensor source to operate from external or onboard mode. Onboard Sensor (Default) 1-2 close Function Setting On Board Thermistor Reserved Pin 3 is reserved for Axiomtek’s device use only ※ Introduction...

  • Page 48: Riser Card- Pcie X16 Gen3 & 3 Pcie X4 Gen 3 (Ax96410)

     1 x system fan connectors  1 x 24V power connector (black, ATX1, for Axiomtek’s device only)  1 x 12V power connector (white, ATX2, for Axiomtek’s device only) Note: Please refer to chapter 1.2.2 for the maximum power rating limitation of expansion slots.
  • Page 49 Temperature Sensor Source Select (JP1) Use these jumpers (3x1-Pin P=2.54mm) to set temperature sensor source to operate from external or onboard mode. Onboard Sensor (Default) 1-2 close Function Setting On Board Thermistor Reserved Pin 3 is reserved for Axiomtek’s device use only. ※ Introduction...

  • Page 50: Riser Card- Pcie X16 Gen3 & 1 Pcie X4 Gen 3 & 2 Pci (Ax96411)

     1 x system fan connectors  1 x 24V power connector (black, ATX1, for Axiomtek’s device only)  1 x 12V power connector (white, ATX2, for Axiomtek’s device only) Note: Please refer to chapter 1.2.2 for the maximum power rating limitation of expansion slots.
  • Page 51 Temperature Sensor Source Select (JP1) Use these jumpers (3x1-Pin P=2.54mm) to set temperature sensor source to operate from external or onboard mode. Onboard Sensor (Default) 1-2 close Function Setting On Board Thermistor Reserved Pin 3 is reserved for Axiomtek’s device use only. ※ Introduction...
  • Page 52 IPC960/IPC962/IPC964-525 Series User’s Manual This page is intentionally left blank. Introduction...

  • Page 53: Section 2 Hardware Installation

    IPC960/IPC962/IPC964-525 Series User’s Manual SECTION 2 HARDWARE INSTALLATION The IPC960-525/IPC962-525/IPC964-525 Series products are convenient for your various hardware configurations, such as CPU (Central Processing Unit), memory module, HDD (Hard Disk Drive) and PCIe/PCI card. Chapter 2 will show you how to install these hardware parts.

  • Page 54: Procedure Of Installation

    IPC960/IPC962/IPC964-525 Series User’s Manual Procedure of Installation This chapter will guide you on installing a processor. Step 1 Turn off the system. Step 2 Disconnect the power connector. Step 3 Loosen four screws to remove the heatsink cover from the chassis. Step 4 After opening the heatsink cover, you can locate the CPU socket as marked.

  • Page 55: Installing The Memory Module

    IPC960/IPC962/IPC964-525 Series User’s Manual Step 5 Apply thermal grease on top of the CPU. Step 6 After installing all components, close the heatsink cover back to the chassis and fasten all screws. Installing the Memory Module Step 1 Turn off the system. Step 2 Disconnect the power connector.

  • Page 56: Installing The Hard Disk Drive

    IPC960/IPC962/IPC964-525 Series User’s Manual Step 4 Install the SO-DIMM (small outline dual in-line memory module) into the socket and push it firmly down until it is fully seated. The socket latches are clipped onto the edges of the memory module. ...
  • Page 57 IPC960/IPC962/IPC964-525 Series User’s Manual Step 5 Align the connector of the HDD/SSD with the SATA slot of main board. Then, insert the HDD into the HDD tray. Note: When using 7mm height HDD/SDD, please take the HDD spacer out of the accessory box and follow the following steps to stick it on HDD/SSD.

  • Page 58: Installing The Expansion Box Kit

    IPC960/IPC962/IPC964-525 Series User’s Manual Step 6 Screw the bracket. The installation is complete. Note: The description of the 2.5" HDD tray (2in1) is as shown below. Installing the expansion box kit The IPC960-525-FL provides two/four-slot expansion box kit for expansion purposes. The procedure of installing the expansion box kit into system is instructed below.
  • Page 59 IPC960/IPC962/IPC964-525 Series User’s Manual Step 4 Loosen the screw to remove the system cover from the expansion box kit. Hardware Installation...
  • Page 60 IPC960/IPC962/IPC964-525 Series User’s Manual Step 5 Align the PCI or PCIe card with the slot, and press the card into the slot until it is firmly seated and screw it. .--> Step 6 After installing the expansion box kit, close the system cover back to the chassis and fasten the screw.

  • Page 61: Installing The Fan Module

    IPC960/IPC962/IPC964-525 Series User’s Manual Installing the Fan Module The IPC962-525-FL/IPC964-525-FL provides either an internal fan module or an external fan module for optional selection. The procedure of installing the fan module into system is instructed below. 2.6.1 Installing Internal Fan Module Step 1 Please take the Mylar out of the accessory box.
  • Page 62 IPC960/IPC962/IPC964-525 Series User’s Manual Step 4 Unscrew the system cover screw and remove the cover from the expansion box.  Step 5 Unscrew the bracket, fasten the fan module into the expansion box and plug cable(s) to connector(s).   Step 6 After installing the fan module, close the system cover back to the chassis and fasten the screw.

  • Page 63: Installing External Fan Module

    IPC960/IPC962/IPC964-525 Series User’s Manual 2.6.2 Installing external Fan Module Step 1 Please take the Mylar out of the accessory box. Screw the fan to the fan bracket. IPC962 series    IPC964 series   Step 2 Turn off the system. Step 3 Disconnect the power connector.

  • Page 64: Installing Pci Or Pcie Card

    IPC960/IPC962/IPC964-525 Series User’s Manual Step 5 Unscrew the bracket, fasten the fan module into the expansion box and plug cable(s) to connector(s).   Step 6 After installing the fan module, close the system cover back to the chassis and fasten the screw.
  • Page 65 IPC960/IPC962/IPC964-525 Series User’s Manual Step 4 Locate the PCI or PCIe slots and remove the slot bracket from the slot in which you want to add the card. Step 5 Align the PCI or PCIe card with the slot, press the card into the slot until it is firmly seated and screw it.
  • Page 66 IPC960/IPC962/IPC964-525 Series User’s Manual Step 7 IPC962 and IPC964 offer 3 types of extension holder brackets . Please take the brackets and screws from the accessory box and assemble the extension holder bracket. The procedure is illustrated below. Step 8 Assemble the extension holder bracket, as illustrated below.

  • Page 67: The Height Limitation Of An Add-On Card

    IPC960/IPC962/IPC964-525 Series User’s Manual Step 9 Fasten the holder bracket in the chassis, a djust the screw position of the extension bracket to fix the add-on card, and then screw it. Step 10 Close the cover back to the chassis and fasten the screw. The installation is complete.

  • Page 68: The Length Limitation Of An Add-On Card

    IPC960/IPC962/IPC964-525 Series User’s Manual 2.7.3 The length limitation of an add-on card The following figures show the length limitation of an add-in card. IPC962 IPC964 System configuration: w/o add-on card power cable & w/o internal fan module Note: Please note that 234mm is the maximum length for add-on card with I/O bracket. Considering heat dissipation potential, a space of 30mm must be left between add-on card and system.
  • Page 69 IPC960/IPC962/IPC964-525 Series User’s Manual IPC962 IPC964 System configuration: w/o add-on card power cable & w/ internal fan module Note: Please note that 210mm is the Note: Please note that 220mm is the maximum internal length for add-on card with maximum internal length for add-on card with I/O bracket.

  • Page 70: Inatalling T4 Graphics Card W/T4 Fan Module

    IPC960/IPC962/IPC964-525 Series User’s Manual 2.7.4 Inatalling T4 graphics card w/T4 fan module Step 1 Please take the Mylar from the accessory box. Then past e it on the cover ‘s vents.  Step 2 Please take the fan module kit from the accessory box. Hardware Installation...
  • Page 71 IPC960/IPC962/IPC964-525 Series User’s Manual Step 3 Screw the eight screws into fan and fan bracket. Step 4 Paste the 4 poron pads on air duct brackets, as illustrated below.     Step 5 Screw the bracket into chassis. Hardware Installation...
  • Page 72 IPC960/IPC962/IPC964-525 Series User’s Manual Step 6 Screw the fan module into chassis and plug in the fan connectors.   Step 7 Route the cables and put the cables in red mark area, as illustrated below. Step 8 Remove the slot brackets. Hardware Installation...
  • Page 73 IPC960/IPC962/IPC964-525 Series User’s Manual Step 9 Insert the air duct bracket’s metal part as marked A below and screw the 4 screws.  Step 10 Align the T4 card with the slot, press the card into the slot until it is firml y seated, and screw the T4 card bracket and slot bracket to the chassis.
  • Page 74 IPC960/IPC962/IPC964-525 Series User’s Manual  Step 12 Paste the Mylar on the vents of the system cover.  Step 13 Close the cover back to the chassis and fasten the screw. The installation is complete. Note: Please note the T4 FAN module kit supports IPC962 w/AX96205 and IPC960 w/AX96205 expansion box kit only.
  • Page 75 IPC960/IPC962/IPC964-525 Series User’s Manual IPC962 System configuration: w/ AX96205 & T4 & w/ T4 fan module kit Note: Please note that 165mm of the 2 slot is the maximum length for add-on card with I/O bracket. considering heat dissipation potential, a space of 5mm must be kept between the add-on card and T4 fan bracket.

  • Page 76: Installing The Mini Card Module

    IPC960/IPC962/IPC964-525 Series User’s Manual Installing the Mini Card Module The IPC960, IPC962 and IPC964 come with a mini card slot for users to install a wireless LAN card. Please refer to the following instructions and illustrations for the installation of the wireless LAN.

  • Page 77: Installing The 5G Wireless Module

    IPC960/IPC962/IPC964-525 Series User’s Manual Step 6 Remove the antenna plugs from the top of back cover, and then install the antennas on the antenna connectors. Step 7 Close the cover back to the chassis and fasten all screws. The installation is complete.
  • Page 78 IPC960/IPC962/IPC964-525 Series User’s Manual Step 3 Turn off the system. Step 4 Disconnect the power connector. Step 5 Loosen screws to remove the heatsink cover from the chassis. Step 6 Insert the 5G wireless module into the slot and push it down firmly. Then screw the card tightly to the mainboard.
  • Page 79 IPC960/IPC962/IPC964-525 Series User’s Manual Step 8 Remove the antenna plugs from the top of the back cover, install the antennas on the antenna connectors as marked in the illustration below, and then insert the SIM card into the SIM slot. SIM slot ...

  • Page 80: 2.10 Installing The Nvme Ssd Module

    IPC960/IPC962/IPC964-525 Series User’s Manual 2.10 Installing the NVMe SSD Module The IPC960, IPC962 and IPC964 come with an M.2 Key M 2280 socket (PCIe Gen3 x4) for users to install an NVMe SSD module. Please refer to the following instructions and illustrations for the installation of the NVMe SSD module.
  • Page 81 IPC960/IPC962/IPC964-525 Series User’s Manual Step 6 Insert the SSD card to slot and push it down firmly. Then screw the card tightly to the mainboard.  Step 7 Paste the other thermal pad on the module and then remove the protective film, as illustrated below.

  • Page 82: 2.11 Mounting

    IPC960/IPC962/IPC964-525 Series User’s Manual 2.11 Mounting The IPC960-525/IPC962-525/IPC964-525 provides versatile mount kits for optional selection. DIN rail mounting Note: The DIN rail kit can be installed in IPC960 system only. Wall mounting Note: The IPC960 supports either DIN rail kit or wall mount kit. Hardware Installation...
  • Page 83 IPC960/IPC962/IPC964-525 Series User’s Manual IPC960-525 System w/ din rail kit System w/ wall mount kit Hardware Installation...
  • Page 84 IPC960/IPC962/IPC964-525 Series User’s Manual IPC962-525 System w/ wall mount kit System w/ external fan module and wall mount kit Hardware Installation...
  • Page 85 IPC960/IPC962/IPC964-525 Series User’s Manual IPC964-525 System w/ wall mount kit System w/ external fan module and wall mount kit Hardware Installation...
  • Page 86 IPC960/IPC962/IPC964-525 Series User’s Manual This page is intentionally left blank. Hardware Installation...

  • Page 87: Section 3 Ami Bios Utility

    IPC960/IPC962/IPC964-525 Series User’s Manual SECTION 3 AMI BIOS UTILITY The AMI UEFI BIOS provides users with a built-in setup program to modify basic system configuration. All configured parameters are stored in a 16MB flash chip to save the setup information whenever the power is turned off. This chapter provides users with detailed description about how to set up basic system configuration through the AMI BIOS setup utility.

  • Page 88: Navigation Keys

    IPC960/IPC962/IPC964-525 Series User’s Manual Navigation Keys The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup utility hot keys can be used at any time during the setup navigation process. These keys include <F1>, <F2>, <Enter>, <ESC>, <Arrow> keys, and so on. Note: Some of the navigation keys differ from one screen to another.

  • Page 89: Main Menu

    IPC960/IPC962/IPC964-525 Series User’s Manual Main Menu The first time you enter the setup utility, you will be in the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as described below.

  • Page 90: Advanced Menu

    IPC960/IPC962/IPC964-525 Series User’s Manual Advanced Menu  Launch PXE OpROM Use this item to enable or disable the boot ROM function of the onboard LAN chip when the system boots up. The Advanced menu also allows users to set configuration of the CPU and other system devices.
  • Page 91 IPC960/IPC962/IPC964-525 Series User’s Manual  HW Monitor This screen monitors hardware health. AMI BIOS Utility...
  • Page 92 IPC960/IPC962/IPC964-525 Series User’s Manual  7802Y HW Monitor This screen monitors fan speed. AMI BIOS Utility...
  • Page 93 IPC960/IPC962/IPC964-525 Series User’s Manual  Ethercat Configuration Setting “Disable” mode in the following 5 times to support Ethercat. AMI BIOS Utility...
  • Page 94 IPC960/IPC962/IPC964-525 Series User’s Manual  Display ME firmware information. AMI BIOS Utility...
  • Page 95 IPC960/IPC962/IPC964-525 Series User’s Manual  ACPI Settings ACPI configuration can be configured in ACPI Settings. A description of the selected item appears on the right side of the screen.  ACPI Sleep State Select the highest ACPI sleep state the system will enter when the suspend button is pressed.
  • Page 96 IPC960/IPC962/IPC964-525 Series User’s Manual  Trusted Computing Select Security Device Support to enable or disable the TPM function. AMI BIOS Utility...
  • Page 97 IPC960/IPC962/IPC964-525 Series User’s Manual  CPU Configuration This screen shows the CPU configuration, and you can change the value of the selected option.  Intel Virtualization Technology This item allows a hardware platform to run multiple operating systems separately and simultaneously, enabling one system to virtually function as several systems.
  • Page 98 IPC960/IPC962/IPC964-525 Series User’s Manual  SATA and RST Configuration You can read the current installed hardware configurations from those SATA ports in the SATA and RST Configuration menu. During system boot up, BIOS will detect the present SATA devices automatically. AMI BIOS Utility...
  • Page 99 IPC960/IPC962/IPC964-525 Series User’s Manual  AMT Configuration AMI BIOS Utility...
  • Page 100 IPC960/IPC962/IPC964-525 Series User’s Manual  USB Configuration USB configuration can be configured here by selecting and changing each item. A description of the selected item appears on the right side of the screen.  USB Devices Display all detected USB devices. AMI BIOS Utility...
  • Page 101 IPC960/IPC962/IPC964-525 Series User’s Manual  F81803 Super IO Configuration  Serial Port 1~4 Configuration Use this item to set parameters of serial port 1 to 4. AMI BIOS Utility...
  • Page 102 IPC960/IPC962/IPC964-525 Series User’s Manual  Serial Port (1~4) Console  COM Port Type Use this item to set parameters of RS232/422/485. AMI BIOS Utility...
  • Page 103 IPC960/IPC962/IPC964-525 Series User’s Manual  Compatibility Support Module (CSM) Configuration AMI BIOS Utility...
  • Page 104 IPC960/IPC962/IPC964-525 Series User’s Manual  PCI Subsystem Setting AMI BIOS Utility...

  • Page 105: Chipset Menu

    IPC960/IPC962/IPC964-525 Series User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: AMI BIOS Utility...
  • Page 106 IPC960/IPC962/IPC964-525 Series User’s Manual ► System Agent (SA) Configuration For items marked with “”, please press <Enter> for more options. AMI BIOS Utility...
  • Page 107 IPC960/IPC962/IPC964-525 Series User’s Manual  PEG Port Configuration  PEG Port Feature Configuration AMI BIOS Utility...
  • Page 108 IPC960/IPC962/IPC964-525 Series User’s Manual  Graphics Configuration  Display Select Allows you to select which graphics controller to use as the primary boot device. AMI BIOS Utility...
  • Page 109 IPC960/IPC962/IPC964-525 Series User’s Manual  Memory Configuration AMI BIOS Utility...

  • Page 110: Security Menu

    IPC960/IPC962/IPC964-525 Series User’s Manual Security Menu The Security menu allows users to change the security settings for the system.  Administrator Password This item indicates whether an administrator password has been set (installed or uninstalled).  User Password This item indicates whether an user password has been set (installed or uninstalled).

  • Page 111: Boot Menu

    IPC960/IPC962/IPC964-525 Series User’s Manual Boot Menu The Boot menu allows users to change boot options of the system.  Setup Prompt Timeout Set the number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.  Bootup NumLock State Use this item to select the power-on state for the keyboard NumLock.

  • Page 112: Save & Exit Menu

    IPC960/IPC962/IPC964-525 Series User’s Manual Save & Exit Menu The Save & Exit menu allows users to load your system configuration with optimal or fail-safe default values.  Save Changes and Exit When finishing the system configuration settings, select this option to leave Setup and return to Main Menu.
  • Page 113 IPC960/IPC962/IPC964-525 Series User’s Manual  Discard Changes and Reset Select this option to quit Setup without making any permanent changes to the system configuration and reboot the computer. Select Discard Changes and Reset from the Save & Exit menu and press <Enter>. Select Yes to discard changes and reset. ...
  • Page 114 IPC960/IPC962/IPC964-525 Series User’s Manual This page is intentionally left blank. AMI BIOS Utility...

  • Page 115: Appendix Awatchdog Timer

    IPC960/IPC962/IPC964-525 Series User’s Manual APPENDIX A WATCHDOG TIMER A.1 About Watchdog Timer Software stability is a major issue in most applications. Some embedded systems are not watched by an operator for 24 hours. It is usually too late to wait for someone to reboot when computer hangs.
  • Page 116 IPC960/IPC962/IPC964-525 Series User’s Manual Begin Begin Next Next Enable and Initialize Enable and Initialize Watchdog Timer Watchdog Timer Next Next Program “A” Program “A” Next Next Disable Watchdog Reset Watchdog Timer Timer Next Next Watchdog Timer...
  • Page 117 IPC960/IPC962/IPC964-525 Series User’s Manual Sample Program Assembly sample code: ;Enable WDT: dx,2Eh al,87 ;Un-lock super I/O dx,al dx,al ;Select Logic device: dx,2Eh al,07h dx,al dx,2Fh al,07h dx,al ;Enable WDT base address: dx,2Eh al,30h dx,al dx,2Fh al,01h dx,al ;Activate WDT: dx,2Eh al,0F0h dx,al dx,2Fh...
  • Page 118 IPC960/IPC962/IPC964-525 Series User’s Manual dx,al dx,2Fh al,Mh ;M=00h,01h,...FFh (hex),Value=0 to 255 Note dx,al ;(see below) ;Set Second or Minute : dx,2Eh al,0F5h dx,al dx,2Fh al,Nh ;N=71h or 79h(see Note below) dx,al Note: If N=71h, the time base is set to second. M = time value 00: Time-out disable 01: Time-out occurs after 1 second...

  • Page 119: Appendix Bconfiguring Sata For Raid

    IPC960/IPC962/IPC964-525 Series User’s Manual APPENDIX B CONFIGURING SATA FOR RAID ® Configuring SATA Hard Drive(s) for RAID (Controller: Intel Q370) Before you begin the SATA configuration, please prepare four SATA hard drives (to ensure optimal performance, it is recommended that you use two hard drives with the identical model and capacity).
  • Page 120 IPC960/IPC962/IPC964-525 Series User’s Manual A list of options appears. Please select “Intel RST Premium”. Save and exit the BIOS Setup. 2.2. 3. Configuring RAID by the RAID BIOS. Enter the RAID BIOS setup utility to configure a RAID array. Skip this step and proceed if you do not want to create a RAID.
  • Page 121 IPC960/IPC962/IPC964-525 Series User’s Manual After entering the Create Volume Menu screen, you can type the disk array name with 3.3. 1~16 letters (letters cannot be special characters) in the item “Name:”. When finished, press <Enter> to select a RAID level. There are two RAID levels: 3.4.
  • Page 122 IPC960/IPC962/IPC964-525 Series User’s Manual Set the stripe block size. The KB is the standard unit of stripe block size. The stripe 3.5. block size can be 4KB to 128KB. After the setting, press <Enter> for the array capacity. After setting all the items on the menu, select Create Volume and press <Enter> to 3.6.
  • Page 123 IPC960/IPC962/IPC964-525 Series User’s Manual When prompting for confirmation, press <Y> to create this volume, or <N> to cancel 3.7. the creation. After the creation is complete, you will see detailed information about the RAID array in the Disk/Volume Information section, including RAID mode, disk block size, disk name, disk capacity, etc.
  • Page 124 IPC960/IPC962/IPC964-525 Series User’s Manual Delete RAID volume If you want to delete a RAID volume, select the Delete RAID Volume option in Main Menu. Press <Enter> and follow on-screen instructions. Please press <Esc> to exit the RAID BIOS utility. Now, you can proceed to install a SATA driver controller and the operating system.

This manual is also suitable for:

Ipc962-525 seriesIpc964-525 seriesIpc960-525-fl

Table of Contents
