DIO1
Pin
Function
1
Common1 PWR+
2
DO10
3
DO11
4
DO12
5
DO13
6
Common1 PWR-
7
External1 Power
8
DI10
9
DI11
10
DI12
11
DI13
12
Isolation1 GND
Introduction
IPC960A/IPC962A/IPC964A Series User's Manual
DIO2
Pin
Function
1
Common2 PWR+
2
DO20
3
DO21
4
DO22
5
DO23
6
Common2 PWR-
7
External2 Power
8
DI20
9
DI21
10
DI22
11
DI23
12
Isolation2 GND
