Connectors

1.2.10
Signals go to other parts of the system through connectors. Loose or improper connection might
cause problems, please make sure all connectors are properly and firmly connected. Here is a
summary table which shows all connectors on the hardware.
PSB521
3 pin terminal block for Power Input
COM Port with RS232 / RS422 /RS485
Battery Connector
DDR4 SODIMM Socket
HDMI output Connector
USB3.1 *2 Connector
LAN connector
M.2 B-key 3052/3042 (USB3.1 / PCIe interface)
Nano SIM card slot
Mini Card Solt1(USB2.0 interface)
Mini Card Solt2(USB2.0 / PCIe / mSATA interface)
IO Connector
SATA+Power
Tact switch for clear CMOS
Tact switch for Reset
AX93670(Full Mode)
IO Connector
COM Port with RS232 / RS422 /RS485
Digital I Connector
Digital O Connector
8
Connectors
Connectors
Label
CN3
CN15/CN16
BAT1
DIMM1
CN8
CN11
CN12/CN13/CN14
CN1
CN4/CN6
CN9
CN7
CN10
CN2/SATA1
SW2
SW1
Label
CN1
CN2/CN3
CN5
CN4
