IPC960A/IPC962A/IPC964A Series User's Manual
Internal fan module is installed.
height
width
The following shows each slot's max. length for add-in card in the system with different configurations.
Riser card power
and (or) USB
device are (is) un-
installed.
Riser card power
and (or) USB
device are (is)
installed.
60
Slot 1
(PCIe x4)
(PCIe x4 or PCI)
1-slot
244.27 (mm)
244.27 (mm)
189.33 (mm)
244.27 (mm)
Slot 2
Slot 3
(PCIe x16)
46.08-116.38 (mm)
1-slot
1-slot
244.27 (mm)
244.27 (mm)
Slot 4
(PCIe x4 or PCI)
2-slot
244.27 (mm)
244.27 (mm)
Hardware Installation
