1.8.13 Power On/OFF Button & LED (SW2)
The power button is on the I/O side. It allows users to control IPC96xA power on/off, The LED displays
the current status, refer to the table below for information.
Function
Description
On
Turn on/off system
Off
Keep system status
Power button LED
Orange
Blue
Blinking 4 times on cycle
Function
Description
Program LED 1
User defined green (On/Off/Blinking)*1
Program LED 2
User defined green (On/Off/Blinking)*1
Program LED 3
User defined green (On/Off/Blinking)*1
HDD LED
HDD Read/Write, Green blinking
Note
: 1 For usage details, please contact the Axiomtek service window
Introduction
IPC960A/IPC962A/IPC964A Series User's Manual
Description
System shut down
System power on
Input power under Low Voltage
27
