(8)-5 XY display settings
Perform XY display setting when starting XY execution.
For details, refer to "3.5 Setting Menus" - "(3) DISP settings" - "3 XY display". This is a common setting.
You can set it again during XY replaying.
(8)-6 XY Execution
Perform XY display according to the XY display settings.
All data XY execution: XY display is executed for all data that is being replayed.
XY execution between cursors: XY display is executed for data between cursors A and B.
* When the amount of data is large, it may take time to draw the waveform of XY display.
(8)-7 Reflecting XY display
When XY display setting is changed during XY replaying, XY waveform is redrawn for reflection from the XY
display setting.
* When the amount of data is large, it may take time to draw the waveform of the XY display.
(8)-8 XY overwrite
Perform XY overwrite settings.
For details, refer to "3.5 Setting Menus" - "(3) DISP settings" - "3 XY display" - "XY overwrite ". This is a
common setting.
(8)-9 Change to Y-T display
Perform Y-T display with data that is being executed currently in XY display.
