CHAPTER 1 General Description
When using the device, be sure to set the device vertically, or use the tilt foot and tilt stand to operate the
device.
Tilt foot
•
Do not block the air vent on this device, as this will cause malfunctioning.
•
Measurement accuracy may not be accurate if the system is used in a condition other than described
above.
•
If using this device in a tilted state, please use both tilt foot and tilt stand for this device to prevent it
from falling.
1-4
Vertical state
Tilt stand
Inclined state
Tilt stand
90°
