(2)-11 Recording destination file name (file capture)
Set the file name and folder name of the recording destination when capturing data.
< When the automatic naming method is used >
< When any file name and serial number is used for naming method >
< When CSV file is used as file format >
Setting
(1) File Type
(2) Name Type
(3) Folder
(4) Prefix
(5) File
(6) CSV decimal point
(7) CSV delimiter
The file should be saved in the folder you created. When the data files continue to save in the root folder,
the file may be not saved regardless of the remaining memory capacity due to the limitations of the file
system .
(1)
(2)
(3)
(4)
(5)
(6)
(7)
Set the file format of data.
GBD: The data file is created in our own binary format.
* Data cannot be changed.
CSV: The data file is created in text format.
Set the naming method for the data file.
Auto: File name is created automatically
Example) 20170728-123456.GBD
Numbers: Date and time when the file is created
* The above example shows July 28, 2017 12:34:56
Arbitrary: Captured data is saved to the file with the file name you entered.
Serial number: Recorded data is saved to the file with the file name you entered and the
serial number.
Example) When the file name is set to "TEST"
1st time: TEST_SER1.GBD
2nd time: TEST_SER2.GBD
3rd time: TEST_SER3.GBD
* If the same file name already exists, "_CP*" is added to the end of the file name to avoid
any overwrite.
The part of * is a number.
Example) TEST_CP1.GBD
Set the folder of saving destination when Auto is selected as the naming method.
Set the prefix character string of the file name.
When a prefix character string is set, the prefix character string set before the automatically
created file name (date/time/time file name) is added.
Example) When "PRIFIX" is set as prefix character,
The file name is "PRIFIX_20170728-123456.GBD".
Set the saving file name when Arbitrary and Serial number is selected in naming method.
The folder for saving the file is displayed in the Folder.
Set the decimal point character of the CSV file.
Period (.), Comma (,)
Set the delimiter of the CSV file.
Comma (.), Tab, Semicolon (;)
