See the description of the
This command is saved to global non-volatile memory and is not part of a preset. Its value is saved each
time it is changed. It will retain its value after power-down. Since this command writes to non-volatile
memory, there will be a delay before an acknowledgment is returned.

8.101. MACROX -- Execute Macro

This command executes the macro corresponding to the specified number. The macro must have been
previously defined and stored in non-volatile memory via the MACROS, MACROA, and
the specified macro is empty, then an error condition of ERROR#070 will be generated.
When the MACROX executes, status messages for all of the commands in the macro will be generated (unless
acknowledgement mode
command, which is exactly the same as MACROX except that status messages are suppressed.
Example Description
B01MACROX125 Execute macro number 125.
8.102. METER -- Select which Signal is Displayed on the Front
Panel LED Meter
This command selects which signal is displayed on the front panel LED meter. The options correspond to any
of the 8 inputs, the telephone input, 8 outputs, the telephone output, the power amplifier output, or the two
AEC references. The inputs are specified by the labels I1 - I4, IA - ID, and IT (for the telephone input).
The outputs are specified by the labels O1 - O4, OA - OD, OT (telephone), and OL (power amplifier). The AEC
references are specified by the labels R1 and R2.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description
Set front panel LED meter to display the
B01METERI1
signal on input 1 .
Query which signal the front panel LED
B01METER?
meter is currently set to monitor.
8.103. MGAIN -- Set Crosspoint Gains in Main Matrix or
Submatrix
This command sets or queries one or more crosspoint gains in either the main matrix or one of the EF Bus
submatrices.
command for detailed information on creating macros.
MACROA
is turned off). The status messages can be suppressed by using the
Status Message
Status messages for all the commands in the macro will be
generated first, followed by the message: B01MACROX125
Status Message
B01METERI1
B01METERx , where x is the label
corresponding to the signal currently being
monitored. If this command was sent after the
first example given above, the response would
be B01METERI1 .
commands. If
MACROW
MACROQ
