disabled. Acknowledgements will be sent for any changes to channel D. From then on, any changes for these
commands for either channel C or D will be set for both channels, and acknowledgements will be sent for
both channels.
This command is a boolean command. See
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description
Enable stereo AGC linking on
B01LAGCLINKCD1
inputs C and D.
Disable stereo AGC linking on
B01LAGCLINKCD0
inputs C and D.
Toggle stereo AGC linking on
B01LAGCLINKCD2
inputs C and D.
Query status of stereo AGC linking
B01LAGCLINKCD?
on inputs C and D.

8.73. LAGCMAX -- Set Maximum Allowed Line Input AGC Gain

This command sets the maximum gain that the AGC can apply on input channels A-D . For example, if
LAGCMAX is set to 10, then the AGC for that channel can apply a maximum of 10 dB of gain to the input
signal.
This command was introduced in firmware version 2.5.0.
This command is a channel integer command. See
type of command. The minimum and maximum values for this command are 0 and 15, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example
B01LAGCMAXA3
B01LAGCMAXB?
B01LAGCMAX*6
B01LAGCMAX*ääìì
Section 6.1
Description
Set AGC maximum gain on input
channel A to 3 dB.
Query the AGC maximum gain on
input channel B.
Set AGC maximum gain on input
channels A-D to 6 dB.
Set AGC maximum gain on input
channels A-B to 0 dB and AGC
maximum gain on input channels
C-D to 9 dB.
for more information on this type of command.
Status Message
B01LAGCLINKCD1
B01LAGCLINKCD0
B01LAGCLINKCDx , where x is 0 or 1 depending
on the current state of stereo AGC linking on inputs
C and D.
B01LAGCLINKCDx , where x is 0 or 1 depending
on the current state of stereo AGC linking on inputs
C and D.
Section 6.3 and Section 6.2
Status Message
B01LAGCMAXA3
B01LAGCMAXBx , where x is a number between 0
and 15, depending on the current setting of the
AGC maximum gain on input channel B.
B01LAGCMAX*èèèè
B01LAGCMAX*ääìì
for more information on this
