is an additional gain stage, referred to as a fader. The fader gain is adjustable by the FADERI command. The
setting should be used for calilbration in order to maximize the resolution and quality of the signal at
GAINI
the analog to digital converter. The FADERI command is provided as a way to do volume control on the
inputs without affecting the calibration.
This command also adjusts the fader gain of the input signal coming from the telephone interface.
This command was introduced in firmware version 2.5.0.
This command is a channel integer command. See
type of command. The minimum and maximum values for this command are -100 and 20, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example
B01FADERIT10
B01FADERIT?
B01FADERI*6
B01FADERI*ääääììììä
B01FADERI*?

8.50. FLASH -- Execute Hook Flash

This command puts the phone on-hook and then takes it back off-hook after a delay. The amount of time
between on-hook and off-hook is controlled by the
each country's specific compliance requirements. If the phone is on-hook when this command is given, then
no action is performed.
Example Description
Description
Set fader gain on input T
to 10 dB.
Query the fader gain on
input T .
Set fader gain on all
inputs (1-4, A-D, T) to 6
dB.
Set fader gain on input
channels 1-4 and T to 0
dB and gain on input
channels A-D to 9 dB.
Query fader gain on all
inputs (1-4, A-D, T) .
Status Message
Section 6.3 and Section 6.2
Status Message
B01FADERIT10
B01FADERITx , where x is a number between 0 and
30, depending on the current setting of the fader
gain on input channel T .
B01FADERI*èèèèèèèèè
B01FADERI*ääääììììä
B01FADERI*abcdefghi, where a-i are each
between ä and ÿ, depending on the current setting
of the fader gains for each of the nine input
channels.
setting and has be set for each country to meet
COUNTRY
for more information on this
