B01LAGCMAX*?

8.74. LAGCMIN -- Set Minimum Allowed Line Input AGC Gain

This command sets the minimum gain that the AGC can apply on input channels A-D . For example, if
LAGCMIN is set to -10, then the AGC for that channel can apply a minimum of -10 dB of gain to the input
signal.
This command was introduced in firmware version 2.5.0.
This command is a channel integer command. See
type of command. The minimum and maximum values for this command are -15 and 0, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example
B01LAGCMINA-3
B01LAGCMINB?
B01LAGCMIN*-6
B01LAGCMIN*ääüü
B01LAGCMIN*?

8.75. LAGCRATE -- Set Ramp Rate of Line Input AGC

This command sets or queries the maximum rate at which the AGC can increase or decrease the gain of the
signals on input channels A-D . The ramp rate is expressed in dB/sec.
This command was introduced in firmware version 2.5.0.
This command is a channel integer command. See
type of command. The minimum and maximum values for this command are 1 and 5, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Query AGC maximum gain on
input channels A-D.
Description
Set AGC minimum gain on input
channel A to -3 dB.
Query the AGC minimum gain on
input channel B.
Set AGC minimum gain in input
channels A-D to -6 dB.
Set AGC minimum gain on input
channels A-B to 0 dB and AGC
minimum gain on input channels
C-D to -3 dB.
Query AGC minimum gain on
input channels A-D.
B01LAGCMAX*abcd , where a-d are each between
ä and É, depending on the current setting of the
AGC maximum gain for each of the four line input
channels.
Section 6.3 and Section 6.2
Status Message
B01LAGCMINA-3
B01LAGCMINBx , where x is a number between -
15 and 0, depending on the current setting of the
AGC minimum gain on input channel B.
B01LAGCMIN*~~~~
B01LAGCMIN*ääüü
B01LAGCMIN*abcd , where a-d are each between
u and ä, depending on the current setting of the
AGC minimum gain for each of the line input
channels.
Section 6.3 and Section 6.2
for more information on this
for more information on this
