B01LAGC*2 Toggle AGC state on input channels A-D.
B01LAGC*? Query AGC state on input channels A-D.
8.71. LAGCLINKAB -- Enable or Disable Stereo AGC Linking on
Inputs A and B
This command links the line input AGC of inputs A and B into a stereo pair. The overall volume level of the
stereo signal will be analyzed, and the same gain will be applied to both channels.
This command has some side effects on the way the other line input AGC commands work. When
LAGCLINKAB is first enabled, the settings for LAGC, LAGCMAX, LAGCMIN, and
be copied to channel B. The original settings for channel B will not be restored after LAGCLINKAB is
disabled. Acknowledgements will be sent for any changes to channel B. From then on, any changes for these
commands for either channel A or B will be set for both channels, and acknowledgements will be sent for
both channels.
This command is a boolean command. See
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description
Enable stereo AGC linking on
B01LAGCLINKAB1
inputs A and B.
Disable stereo AGC linking on
B01LAGCLINKAB0
inputs A and B.
Toggle stereo AGC linking on
B01LAGCLINKAB2
inputs A and B.
Query status of stereo AGC linking
B01LAGCLINKAB?
on inputs A and B.
8.72. LAGCLINKCD -- Enable or Disable Stereo AGC Linking on
Inputs C and D
This command links the line input AGC of inputs C and D into a stereo pair. The overall volume level of the
stereo signal will be analyzed, and the same gain will be applied to both channels.
This command has some side effects on the way the other line input AGC commands work. When
LAGCLINKCD is first enabled, the settings for LAGC, LAGCMAX, LAGCMIN, and
be copied to channel D. The original settings for channel D will not be restored after LAGCLINKCD is
B01LAGC*abcd , where a-d are each 0 or 1
depending on the current state of the AGC for each
of the four line input channels.
B01LAGC*abcd , where a-d are each 0 or 1
depending on the current state of the AGC for each
of the four line input channels.
Section 6.1 for more information on this type of command.
Status Message
B01LAGCLINKAB1
B01LAGCLINKAB0
B01LAGCLINKABx , where x is 0 or 1 depending
on the current state of stereo AGC linking on inputs
A and B.
B01LAGCLINKABx , where x is 0 or 1 depending
on the current state of stereo AGC linking on inputs
A and B.
on channel A will
LAGCRATE
on channel C will
LAGCRATE
