Blauto -- Enable Automatic Bldata Messages; Bldata -- Request Level Information - Polycom Vortex EF2241 Programming Manual

Example Description
Set baud rate of rear panel RS-232 port
B01BAUD38400
to 38400 bps.
Query current baud rate of rear panel
B01BAUD?
RS-232 port.

8.31. BLAUTO -- Enable Automatic BLDATA Messages

This command sets whether or not
command for more information.
BLDATA
This command is a boolean command. See
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description
B01BLAUTO0 Disable automatic
B01BLAUTO1 Enable automatic
Toggle enabled status of automatic
B01BLAUTO2
messages.
Query enabled status of automatic
B01BLAUTO?
messages.

8.32. BLDATA -- Request Level Information

This command is used to request "blinking light" data from the EF2241. Blinking light data consists of signal
levels for the 9 inputs (1-4, A-D, T), 10 outputs (1-4, A-D, T, L), and 2 AEC references (R1, R2) as well as
room gain levels for inputs 1-4, AGC gain levels for inputs 1-4, and AEC state information for inputs 1-4.
The blinking light data can be received in two ways. The first way is by polling the Vortex by sending a
BLDATA? command. The second way is to have the Vortex automatically send BLDATA responses via the
command.
BLAUTO
The most general format of the BLDATA responses generated by the Vortex is as follows.
B01BLDATAiiiiiiiiioooooooooorrggggaaaassss
Each of the i, o, r, g, a and s characters above represents a single byte of data as shown in the table
below.
BLDATA Bytes
iiiiiiiii
oooooooooo
messages are automatically generated by the Vortex. See the
BLDATA
Section 6.1
messages.
BLDATA
messages.
BLDATA
BLDATA
BLDATA
Meaning
input levels 1-4, A-D, T
output levels 1-4, A-D, T, L
Status Message
B01BAUD38400
B01BAUDx , where x is 9600, 19200, or 38400
depending on the current baud rate setting.
for more information on this type of command.
Status Message
B01BLAUTO0
B01BLAUTO1
B01BLAUTOx , where x is 0 or 1 depending
on the current setting of BLAUTO.
B01BLAUTOx , where x is 0 or 1 depending
on the current setting of BLAUTO.
