Maximum charging current (Max current field): the maximum current selected, expressed
>
in Amperes, determines the maximum charging power that can be delivered by Waybox..
NOTE:
The table below provides power ratings corresponding to different current levels (Amperes).
You can select any current value between 6 and 32 A.
Current
(Ampere)
1-PH
(230 V)
POWER
(KW)
3-PH
(400 V)
NOTE:
When the Waybox is commissioned via the app, the current value indicated in the Imax
parameter of the WebManager is no longer taken into consideration. The current/power
value taken into consideration is the lower of the one set in the app, the one set by the ENEL
control room, the one selected via Waymeter and the Waybox rating. If, due to connectivity
problems, the Waybox is offline, the current value used will be the lower of the one used in
the last charge and the one communicated by the Waymeter (if C2G is active).
>
Supply System (Supply System field): this configuration must be made in case of the
installation of a three-phase Waybox on a single-phase or bi-phase supply system.
Set the value to:
>
Monophase" in case of Single-phase supply system.
>
"Biphase" in case of a Bi-phase supply system.
4. When you have finished the changes, press Save above the settings configured in the
previous point. Restart the device by powering off/on and check that parameters have been
saved.
NOTE (VALID FROM FIRMWARE VERSION JB3VUEV01A):
Please note that if there is no connectivity when installing the Waybox, there is no need
to request that the Waybox be set to standalone mode. The standalone mode does not
allow use of the Enel X Way app and therefore it is not possible to monitor consumption.
The Waybox works correctly even if it is in connected mode but not commissioned.
The maximum current delivered will be that set by the Imax parameter. If connectivity is
subsequently restored (e.g. via an external antenna), the customer will be able to carry out
commissioning via the app.
6
8
10
12
1.4
1.8
2.3
2.8
4.1
5.5
6.9
8.3
14
16
18
20
3.2
3.7
4.1
4.6
9.7
11.1
12.4
13.8 15.2 16.6
REV.2 - 03/2023
22
24
26
28
5.0
5.5
6.0
6.4
18.0
19.4 20.7 22.1
30
32
6.9
7.3
95
