REV.2 - 03/2023

5.2 Power and signal cables

The choice of cross-sections, insulating materials and composition of the power cables
shall be made in line with the size of the switches and in accordance with local standards
in force.
The following table shows the minimum recommended cross sections for a standard
installation using copper cables.
WAYBOX
Up to 3.7 kW, 16 A
Single-
phase
Up to 7,4 kW, 32 A
Three-
Up to 22 kW, 32 A
phase
NOTE:
The maximum conductor cross-section of cables that can be used for Waybox is 10 mm
In this case the maximum conductor diameter shall be 4 mm.
WAYBOX WITH CONTROL BOARD:
Waybox with control board require signal cables with section between 1 and 1.5 mm
external diameter between 2.5 and 3.5 mm.

5.3 JB4Installers App

Enel X Way partners will need to install the JB4Installers app on their smartphone to perform
Waybox configuration and diagnostic tasks. To use the app, they will need to receive
authorization from Enel X Way and complete a registration process. Please refer to the
JB4Installers App Manual

5.4 Enel X Way App

Enel X Way partners will need to install the Enel X Way app on their smartphone to perform
Waybox configuration tasks. Enel X Way app is available on the
For more information, see
18
for more information.
section 10 of this manual.
MINIMUM SECTION
4 mm
2
6 mm
2
6 mm
2
iOS App Store
.
2
and
2
e Google Play.
