POWER
> Connection:
>
Standard Version: Feed the product with terminals "T" and "N", the same that are used
for the voltage measurement.
> IT GRID Version: Feed the product with terminals "T" and "R", the same that are used for
the voltage measurement.
> Nominal voltage: 230 Vac
> Operating voltage range: -20%/+15% of the nominal voltage
Frequency: 50 Hz
>
Power consumption: 120 mA max
>
Protection: Internal Fuse on PCB (F1: T1A 300V) not replaceable. If the fuse breaks, the
>
device switches off and the dynamic modulation of the load fails.
CONNECTIONS
> Terminals: 8 way Screw Terminals.
> Wiring size (min ÷ max): 0.5 ÷ 2.5 mm
WI-FI / BLUETOOTH COMMUNICATION (FEATURE CURRENTLY NOT AVAILABLE)
> Function: Optional commissioning with APP
Antenna: Built in
>
Frequency: 2.4 GHz
>
Standard: 802.11 b/g/n
>
PLC NARROW BAND COMMUNICATION (CHAIN 2)
> Modem: C-Band, B-PSK Modulation
> Application: DLMS/COSEM IEC (IEC 62056-5-3)
> Data Model: COSEM Data Model (IEC 62056-6-1, IEC 62056-6-2)
> Coupling:
Standard version: PLC communication differential mode coupled on terminals "T"
>
and "N".
IT GRID Version: PLC communication differential mode coupled on terminals "T"
>
and "R".
/ 22AWG ÷ 14AWG
