REV.2 - 03/2023
5 Installation Prerequisites
The Waybox must be installed in accordance with the following specifications:
>
Within a useful distance of the vehicle's charging port.
>
For Wi-Fi enabled units: Within range of local Wi-Fi network (supports IEEE 802.11b/g/n
at 2.4 GHz).
>
For units equipped with a cellular data connection (Waybox Pro Cellular and Waybox
Plus Cellular): in an area with good mobile data network coverage. If the reception is
not sufficient, an external antenna will also need to be installed and connected to the
Waybox. The optimal signal strength is greater than or equal to -80 dBm (e.g. -75 dBm is
greater than -80 dBm, because of the minus sign). If the measured signal is less than -80
dBm (e.g. -85 dBm) could be necessary to install a dedicated external antenna. Anyway,
also if an antenna is installed it could not be sufficient.
DEVICE
Wi-Fi
RFID
14
NOTE
IEEE 802.11 b
IEEE 802.11 g
IEEE 802.11 n
Operating bands
RF Power
Operating bands
POWER/OPERATING BANDS
17 dBm (50mW)
13 dBm (20mW)
12 dBm (15mW)
2400 – 2483,5 MHz
27dBm (0.5W)
Fo: 13,56 MHz; bandwidth: 2,26 kHz
