2.1 Data network signal with SIM is insufficient

If Data network coverage with SIM is absent or insufficient (at least -80dBm)
Is it possible to use an external antenna with a cable length < 10 m and is the
signal sufficient at the point chosen for the installation?
Refer to the
Plus installation procedure
and check again if the signal is
sufficient
Don't forget:
1. External antenna with male RP SMA connector -> Waybox
2. Verify and measure that the signal at the antenna point is at least -80dbm net of
antenna gain and attenuation. .
108
YES
Waybox Pro &
If you are authorized to use the
JB4Installers app, you must proceed
with the FW update and configure
your Waybox offline. Please refer to the
JB4installers manual.
Otherwise follow the procedure in the
Web Manager manual
NO
