2.13 Renault Zoe, Smart 22 kW, Twingo Electric

If Does the Customer own a Renault Zoe, Smart 22 kW or Renault Twingo
Electric?
The resistance of the earthing system is < 100 Ohm and
the voltage between live and neutral is less than 10 V RMS and
The distribution system is not IT
Follow the
in the installation

2.14 Load Optimization Pro with transformer

If
Installation requires an isolation transformer (see
Once the transformer and upstream Waymeter are installed, does the
Waybox communicate with the latter effectively and modulate the available
power correctly?
STOP
YES
Standard Installation
YES
Is it necessary to install a transformer
upstream of the station to create a local
TN system?
special case
Load Optimization Pro feature not
implementable
REV.2 - 03/2023
NO
N.12)
NO
117
