7 Special Installation Cases

7.1 Three phase Waybox installed on a Single-phase or
Bi-phase supply system
In the case of installation of a three-phase Waybox on a Single-phase or Bi-phase supply
system it is mandatory to set up the parameter "Supply system" after the Firmware Update
and prior to commissioning of the Waybox. The supply system must be configured as:
>
"Monophase" in case of installation on a single-phase supply system (Vph=230 V, Vn=0)
>
"Biphase" in case of installation on a bi-phase supply system (Vph1=127 V, Vph2=127V)
through one of the following methods:
> Configuration of the "Supply System" parameter through the "JB4Installers" smartphone
app (reserved for Enel X Way partners). To proceed with the configuration please refer to
the JB4Installer App
> Configuration of the "Supply System" parameter through the "Web Manager" Web App
(usable by all users). To proceed with the configuration please refer to the
Manual.

7.2 Other special cases

Should the installer verify the presence of one of the special cases indicated in the
manual, please refer to the procedure defined for the specific case described in the same
manual.

8 Firmware Update

Once the Waybox is installed, it is necessary to perform a firmware update using the
JB4Installers app. To do this, it is necessary to:
> Make sure you have the JB4Installers app installed on your smartphone and the necessary
credentials to log in.
> Download the latest available firmware.
> Add the serial number of the Waybox in the app.
> Proceed with updating the Waybox firmware.
For the detailed procedure, please refer to the
36
Manual.
JB4Installers App Manual.
Web Manager
What-if
