Waybox - Enel X Waybox Pro Installer Manual

REV.2 - 03/2023

1 Waybox

Waybox Pro and Waybox Plus charging stations are available in two versions.
WAYBOX CABLE VERSION (1):
WAYBOX SOCKET VERSION (2):
The Waybox Pro differs from the Waybox Plus by the possibility to enable the Load
Optimization Pro feature, which allows the Customer to always charge at the maximum
available power without triggering the meter. The activation of this function requires the
installation of an additional device, the Waymeter.
Waybox Pro installation: hardware installation of the Waybox, hardware installation of
>
the Waymeter, configuration, testing and acceptance test
Waybox Plus installation: hardware installation of the Waybox, configuration, testing
>
and acceptance test
8
1
1
2
2
3
3
4
4
1
2
1
3
2
3
Cable
RFID reader
LED indicator
Connector
RFID reader
LED indicator
Socket
