REV.2 - 03/2023
USER INTERFACE:
>
Service LED: service indicator (red)
>
Button: for initial configuration and reactivation of the device
REFERENCE REGULATIONS:
Art. 3.1a Safety: EN 61010-1:2010/A1: 2010, EN 61010-2-30:2010
>
Art. 3.1b EMC: EN 55032:2015/A11:2010, EN 55035:2017/A11:2010, EN 61000-3-2:2019,
>
EN 61000-3-3:2013/A1:2019, ETSI EN 301 489-1 V2.2.3 (2019), ETSI EN 301 489-17 V3.2.2
>
Art. 3.2 Radio: ETSI EN 300 328
>
Health: EN 62311

2.2 Installation

Install the Waymeter downstream of the distributor's meter and the main circuit breaker
to enable measurement of total consumption (see diagram below). The protection and
disconnection device of the Waymeter will be the general MCB.
Meter
DSO
48
MCB
Waymeter
max 40A
Main switch
1P
RCD
Other loads
MCB
Waybox
