2.6 Three-phase TT/TN power grid
If
The installation is on TT/TN three-phase grid with 400 VAC voltage.
Power upt to 22kW, 32A
Magnetothermic switch: Curve
C; ICC=10kA; In=40A; 4-pole
Residual Current Device: Type
A; Id=30mA; In=40 A; Poles:4
Don't forget:
1. Magnetothermic Switch
2. Residual Current Device
3. Cables suitable for these cases
YES
Not applicable
See
installation prerequisites
installation manual
REV.2 - 03/2023
NO
in the
113
