Summary of Contents for Enel X JuiceBox Pro

  • Page 1 JuiceBox Pro User Manual...

  • Page 2: Table Of Contents

    Table of contents Welcome to JuiceBox Pro Package Contents Required Tools Installation Installation Prerequisites Installation Load Balancing Locking Your JuiceBox Wi-Fi Setup JuiceBox Configuration Configure JuiceBox Using Bluetooth Connectivity Configure JuiceBox Using Wi-Fi Connectivity Specifications Characteristics Connectivity Dimensions LED Indicator...

  • Page 3: Welcome To Juicebox Pro

    Welcome to JuiceBox Pro Package Contents > JuiceBox NOTE In some markets, JuiceBox arrives secured to a cable holder that includes keys. > Wall bracket > 2 wall bracket screws (#10 self-tapping Phillips head wood screws) > 2 screws to hang JuiceBox onto wall bracket (#10-32 Phillips head machine screws) >...

  • Page 4: Installation

    Installation Installation Prerequisites OVERVIEW JuiceBox requires either a hardwired electrical connection or a NEMA 14-50 outlet. The JuiceBox power supply must be connected to a non-GFI circuit breaker that is rated for at least 125% of the device's continuous load. NOTE Ensure that all power connection wiring conforms to the rules and regulations of any national and local codes.

  • Page 5: Installation

    Fully read and understand the directions before installation. Refer to important safety information at the end of this document. This section describes installing the JuiceBox Pro onto a wall mount. If installing onto a JuiceStand, refer to the JuiceStand Manual.
  • Page 6 Version without cable Version with cable holder holder 3. Insert the enclosure screws into the enclosure, as shown. Tighten the screws until approximately 2 mm of thread are visible. Version with cable holder Version without cable holder...
  • Page 7 4. Hang the JuiceBox onto the wall bracket. NOTE If the JuiceBox does not hang securely, adjust the screws that were installed in step 3. The 48 and 80 amp are hardwire only and do not have a plug as shown. Version with cable holder Version without cable holder 5.

  • Page 8: Load Balancing

    32A/40A L1 (Black) 8 AWG 6 AWG 3 AWG L2 (Red) 8 AWG 6 AWG 3 AWG Ground 8 AWG (THHN) 8 AWG (THHN) 6 AWG (THHN) (Green) 6. Turn on the circuit breaker that supplies power to the NEMA 14-50 outlet, NEMA 6-50 outlet, or hardwired electrical connection.

  • Page 9: Locking Your Juicebox

    Locking Your JuiceBox After installing your JuiceBox, use the included keys to lock the JuiceBox to the wall frame. Wi-Fi Setup 1. Reset the circuit breaker that supplies power to the JuiceBox. NOTE The following steps must be completed within 2 minutes of reconnecting power to the JuiceBox.
  • Page 10 138.91.137.23 8042 jbv1.emotorwerks.com 40.118.171.20 8042 emwjuicebox.emotorwerks.com dynamic HTTPS device-backend.juice.net 4. Select the desired Wi-Fi network. Enter the Wi-Fi network password, if necessary. Click Connect. Verify that the JuiceBox is connected by checking that the LED indicator turns white.

  • Page 11: Juicebox Configuration

    JuiceBox Configuration For best results, perform this procedure while standing within 5 ft (1.6m) of the JuiceBox. Configure JuiceBox Using Bluetooth Connectivity *REQUIRES FIRMWARE 1.0.46 OR LATER 1. Download and install the “JuiceConfigure” app onto your mobile device. Video walkthrough of this section 2.
  • Page 12 3. Select START CONFIGURATION. 4. Follow the onscreen instructions to proceed to JuiceBox configuration.
  • Page 13 5. Chargers are scanned and listed on the screen. Select Pair to configure the charger. 6. Your JuiceBox is now connected to your account.
  • Page 14 7. Wi-Fi networks are scanned and listed on the screen. Select the network you want to connect your JuiceBox to. 8. Enter the password of the selected Wi-Fi network and select Connect charger to Wi-Fi.
  • Page 15 9. The JuiceBox is connected to your account. Select CONTINUE. 10. In the configuration screen, set the maximum current for charger at which you want to charge your vehicle, then select SAVE. NOTE After connecting, JuiceBox checks its firmware version and performs any necessary updates.

  • Page 16: Configure Juicebox Using Wi-Fi Connectivity

    Configure JuiceBox Using Wi-Fi Connectivity 1. Download and install the “JuiceConfigure” app onto your mobile device. Video walkthrough of this section 2. Open the JuiceConfigure app. 3. Select START CONFIGURATION.
  • Page 17 4. Select Configure via Wifi. 5. Have the Wi-Fi network password ready, then select NEXT. NOTE If the JuiceBox is already power on before this step, disconnect it from power and re-connect again before proceeding. NOTE After powering the JuiceBox, complete the steps 6 through 9 within 2 minutes.
  • Page 18 6. Navigate to the Wi-Fi settings on your mobile device. Connect to the “JuiceBox-###” or “JuiceNet-###” Wi-Fi network. If the network requires a password, use the password “GoElectric” (case-sensitive). NOTE The actual name of the network varies by device, such as “JuiceBox-123”. 7.
  • Page 19 8. In the JuiceConfigure app, select the preferred local Wi-Fi network. 9. Enter the Wi-Fi network password, if necessary, then select CONNECT CHARGER TO WI-FI.
  • Page 20 10. The app connects the JuiceBox to the Wi-Fi network, then select CONTINUE. 11. You did it! The JuiceBox is now online and ready to charge. NOTE After connecting, JuiceBox checks its firmware version and performs any necessary updates. Wait 10 minutes before plugging in a vehicle.

  • Page 21: Specifications

    Specifications Characteristics 32A max: Up to 7.7 kW, 32A, 1-phase 40A max: Up to 9.6 kW, 40A, 1-phase OUTPUT POWER 48A max: Up to 11.5 kW, 48A, 1-phase 80A max: Up to 19.2 kW, 80A, 1-phase INPUT VOLTAGE 208 or 240 VAC CHARGING MODE Mode 3 LEDS...

  • Page 22: Dimensions

    Dimensions...

  • Page 24: Led Indicator

    LED Indicator COLOR PATTERN MEANING Orange Pulsing Powering on Blue Flashing Setup Mode Yellow Flashing Vehicle plugged in, charging ended or suspended All white patterns indicate that unit is online Solid Ready to charge White 1 Flash + beep* RFID card swiped Flashing Ready to charge, vehicle not plugged in All purple patterns indicate that unit is offline...

  • Page 25: Using The Dashboard

    Using the Dashboard Enterprise Dashboard Manual To access the JuiceNet Enterprise documentation and FAQs, log into your Enterprise account. Business Dashboard Manual To access the JuiceNet Enterprise documentation and FAQs, log into your Business account. RFID Cards RFID Reader IP ADDRESS PROTOCOL PORTS FQDN...

  • Page 26: Important Safety Information

    Important Safety Information Read all safety information before installing this product. WARNING: This device should be supervised when used around children. WARNING: Do not put fingers into the electric vehicle connector. WARNING: Do not use this product if the flexible power cord is frayed, has broken insulation, or shows any other signs of damage.
  • Page 27 > Reorient or relocate the receiving antenna. > Increase the separation between the equipment and receiver. > Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. > Consult the dealer or an experienced radio/TV technician for help. WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
