Configuration Of The Waybox In Case Of Installation On The It Network Or In Absence Of Neutral; Gpd Disabling Procedure - Enel X Waybox Pro Installer Manual

REV.2 - 03/2023
9.6 Configuration of the Waybox in case of installation
on the IT network or in absence of neutral
It will be necessary to disable GPD by following the procedure in the next paragraph, if the
Waybox is installed in one of the following scenarios:
Single-phase Waybox installed on the IT network.
>
Waybox installed on a network without neutral (for example between two phases).
>

9.7 GPD disabling procedure

NOTE:
This configuration is available only for JB3VUEV02c Firmware version and newer.
To disable the GPD:
1. Select the ADVANCED tab;
2. Select the GPD Enabled tab;
3. Set the value to False;
4. Click SAVE;
5. Click the REBOOT button.
88
