Installation - Enel X Waybox Pro Installer Manual

REV.2 - 03/2023
USER INTERFACE:
> LED Service: Power on Service LED (red)
> Button: For initial configuration and Reset.
STANDARDS
Art. 3.1a Safety: EN 61010-1:2010/A1: 2010, EN EN 61010-2-30:2010
>
Art. 3.1b EMC: EN 55032:2015/A11:2010, EN 55035:2017/A11:2010, EN 61000-3-2:2019,
>
EN 61000-3-3:2013/A1:2019, ETSI EN 301 489-1 V2.2.3 (2019), ETSI EN 301 489-17
V3.2.2
> Art. 3.2 Radio: ETSI EN 300 328
> Health: EN 62311

3.2 Installation

Install the Waymeter down of the distributor meter and the main switch to allow the
measurement of overall consumption (see diagram below).
Meter
DSO
NOTE: For protection of the electrical system circuit, it is recommended to install:
- For Waymeter Standard Version one circuit breaker 3P +N, with a fuse for each phase;
- For Waymeter IT GRID Version one circuit breaker 3P, with a fuse for each phase.
This Circuit Breaker must be marked as Waymeter disconnecting device.
56
Waymeter
max 6A
MCB
max 63A
Main switch
3P
Fuse (*)
Other Loads
RCD MCB Waybox
