Cellular
The Waybox is compatible with the networks in the following table:
DISTRIBUTION
Single-phase
Three-phase
Single-phase
Three-phase
Single-phase
NOTE: Waybox MID version is not compatible with IT grid
NOTE:
The system shall be installed in accordance with applicable local codes.
2G
2G
2G
2G
3G (WCDMA)
4G (FDD & TDD)
Operating bands
NEUTRAL
Yes
TT
Yes
Yes
TN-S
TN-C-S
Yes
IT No
LB Class 4 33dBm (2W)
LB Class E2: 27dBm (0.5W) @ EDGE
HB Class 1: 30dBm (1W)
HB Class E2: 26dBm (0.4W) @ EDGE
Class 3: 24dBm (0.25W)
Class 3: 23dBm (0.2W) @ 1RB
B28A: 703 – 788 MHz
B20: 791 – 862 MHz
B8: 880 – 960 MHz
B3: 1710 – 1880 MHz
B1: 1920 – 2170 MHz
B7: 2500 – 2690 MHz
VOLTAGE
230 VAC
400 VAC
230 VAC
400 VAC
230 VAC
