ADF7021-V
ABSOLUTE MAXIMUM RATINGS
T
= 25°C, unless otherwise noted.
A
Table 7.
Parameter
1
V
to GND
DD
1
Analog I/O Voltage to GND
1
Digital I/O Voltage to GND
Operating Temperature Range
Industrial (B Version)
Storage Temperature Range
Maximum Junction Temperature
MLF θ
Thermal Impedance
JA
Reflow Soldering
Peak Temperature
Time at Peak Temperature
1
GND = GND1 = GND2 = GND4 = RFGND = 0 V.
Rating
−0.3 V to +5 V
−0.3 V to VDDx + 0.3 V
−0.3 V to VDDx + 0.3 V
−40°C to +85°C
−65°C to +125°C
150°C
26°C/W
260°C
40 sec
Rev. 0 | Page 14 of 60
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
This device is a high performance RF integrated circuit with an
ESD rating of <2 kV, and it is ESD sensitive. Proper precautions
should be taken for handling and assembly.
ESD CAUTION
