ADAU1961

ABSOLUTE MAXIMUM RATINGS

Table 7.
Parameter
Power Supply (AVDD)
Input Current (Except Supply Pins)
Analog Input Voltage (Signal Pins)
Digital Input Voltage (Signal Pins)
Operating Temperature Range
Storage Temperature Range
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
Downloaded from Elcodis.com electronic components distributor
Rating
−0.3 V to +3.65 V
±20 mA
−0.3 V to AVDD + 0.3 V
−0.3 V to IOVDD + 0.3 V
−40°C to +105°C
−65°C to +150°C
Rev. 0 | Page 12 of 76

THERMAL RESISTANCE

θ represents thermal resistance, junction-to-ambient; θ
JA
sents thermal resistance, junction-to-case. All characteristics are
for a 4-layer board.
Table 8. Thermal Resistance
Package Type
32-Lead LFCSP

ESD CAUTION

repre-
JC
θ θ Unit
JA JC
50.1 17 °C/W
