SERIAL INTERFACE

The serial interface allows the user to program the 16 32-bit
registers using a 3-wire interface (SCLK, SDATA, and SLE). It
consists of a level shifter, 32-bit shift register, and 16 latches.
Signals should be CMOS compatible. The serial interface is
powered by the regulator and, therefore, is inactive when CE is low.
Data is clocked into the register, MSB first, on the rising edge of
each clock (SCLK). Data is transferred to one of 16 latches on the
rising edge of SLE. The destination latch is determined by the
value of the four control bits (C4 to C1); these bits are the four
LSBs, DB3 to DB0, as shown in Figure 2. Data can also be read
back on the SREAD pin.

READBACK FORMAT

The readback operation is initiated by writing a valid control word
to the readback setup register and enabling the READBACK_
SELECT bit (Register 7, Bit DB8 = 1). The readback can begin
after the control word has been latched with the SLE signal. SLE
must be kept high while the data is being read out. Each active
edge at the SCLK pin successively clocks the readback word out
at the SREAD pin, MSB first (see Figure 57). The data appearing
at the first clock cycle following the latch operation must be
ignored. An extra clock cycle is needed after the 16
bit to return the SREAD pin to tristate. Therefore, 18 total clock
cycles are needed for each readback. After the 18
SLE should be brought low.
AFC Readback
The AFC readback is valid only during the reception of FSK
signals with either the linear or correlator demodulator active.
The AFC readback value is formatted as a signed, 16-bit integer
comprising Bit RV16 to Bit RV1 and is scaled according to the
following formula:
FREQ RB (Hz) = (AFC READBACK × DEMOD CLK)/2
In the absence of frequency errors, FREQ RB is equal to the IF
frequency of 100 kHz. Note that, for the AFC readback to yield
a valid result, the downconverted input signal must not fall outside
the bandwidth of the analog IF filter. At low input signal levels, the
variation in the readback value can be improved by averaging.
READBACK MODE
AFC READBACK
RSSI READBACK
BATTERY VOLTAGE/ADCIN/
TEMP. SENSOR READBACK
SILICON REVISION
FILTER CAL READBACK
th
readback
th
clock cycle,
18
DB15 DB14 DB13 DB12 DB11
RV16 RV15 RV14
RV13 RV12
X X X X X
X X X X X
RV16 RV15 RV14 RV13
RV12
0 0 0 0 0
Figure 57. Readback Value Table
Rev. 0 | Page 43 of 60
RSSI Readback
The format of the RSSI readback word is shown in Figure 57. It
comprises the RSSI-level information (Bit RV7 to Bit RV1), the
current filter gain (FG2, FG1), and the current LNA gain (LG2,
LG1) setting. The filter and LNA gain are coded in accordance
with the definitions in the Register 9—AGC Register section. For
signal levels below −100 dBm, averaging the measured RSSI values
improves accuracy. The input power can be calculated from the
RSSI readback value as described in the RSSI/AGC section.
Readback with AFC or Linear Demodulation On
To perform any readback with the AFC on, the AGC must first be
locked. To lock the AGC, use the LOCK_THRESHOLD_MODE
bits (Bits[DB5:DB4] in Register 12) for packet reception. The lock
threshold mode locks the threshold of the envelope detector, as
well as the AFC and AGC circuits. It can be set to lock on recep-
tion of a valid SWD and remain locked until it is released by a
subsequent SPI command (LOCK_THRESHOLD_MODE = 1).
It can also be set to lock on reception of a valid SWD for a specified
number of bytes by setting LOCK_THRESHOLD_MODE = 2;
or it can be locked at any time by setting LOCK_THRESHOLD_
MODE = 3. After the threshold is locked, a readback can be
performed. The AGC/AFC lock is released by setting
LOCK_THRESHOLD_MODE = 0.
Battery Voltage/ADCIN/Temperature Sensor Readback
The battery voltage is measured at Pin VDD4. The readback
information is contained in Bit RV7 to Bit RV1. This also
applies to the readback of the voltage at the ADCIN pin and the
temperature sensor. From the readback information, the battery
or ADCIN voltage can be determined as follows:
V = (BATTERY VOLTAGE READBACK)/21.1
BATTERY
V = (ADCIN VOLTAGE READBACK)/42.1
ADCIN
The temperature can be calculated as follows:
Temperature (°C) = −40 + [(68.4 − TEMP READBACK) × 9.32]
READBACK VALUE
DB10 DB9 DB8 DB7 DB6
RV11 RV10 RV9 RV8 RV7
LG2 LG1 FG2 FG1 RV7
X X X X RV7
RV11 RV10 RV9 RV8 RV7
0 0 0 RV8 RV7
DB5 DB4 DB3 DB2 DB1
RV6 RV5 RV4 RV3 RV2
RV6 RV5 RV4 RV3 RV2
RV6 RV5 RV4 RV3 RV2
RV6 RV5 RV4 RV3 RV2
RV6 RV5 RV4 RV3 RV2
ADF7021-V
DB0
RV1
RV1
RV1
RV1
RV1
